ARPMG-20KW
ALLRUN
1. Production Presentation:
1. NdFeB, rare earth permanent magnet generator
2. low start-up torque
3. small size, beautiful appearance, low vibration
4. easy installation, maintenance and repair.
5. permanent magnet generator rotor using patented alternator, together with the special stator design, effectively reduce the generation of resistance torque
2. Production Parameter
Model | AR-20kw |
Rated Power(w) | 20kw |
Max Power(w) | 25kw |
Rated Voltage（v) | 220v/380V/420V ( can adjust for your requirement) |
Rated rotated speed(r/m) | 200R/M ( we can adjust for you ) |
Safe Max rotate speed(r/m) | 200 r/m |
Top net weight(kg) | 320kg |
Output Current | AC |
Rated Torque(N*M): | 955 Nm |
Start torque(N*M): | 19.1 Nm |
generator | 3 phase permanent magnet synchronous generator |
Insulation Class: | F |
Service Life: | More Than 25 years |
Bearing | HRB or for your order |
Shaft Material | Iron |
Shell Material | Carbon Steel |
Permanent Magnet Material | Rare Earth NdFeB |
Protection Grade | IP54 |
Lubrication | Lubrication Grease |
Working temperature | -40℃ - 80 ℃ |
Note： We can adjust the products to what you require , such as voltage , RPM , power and so on , so just let us know what you need and how you will use it , Thanks!
