Complete Unit 5KW Vertical Wind Turbine Off Grid

Availability:
Quantity:
  • ARC-5KW

  • ALLRUN



Main technical data as follows:

  • Rated Power 5KW

    Blades C-shaped

    Blades number 5 pc

    Rotor Diameter 4 m

    Blade Length 3600 mm

    Blade Width 210 mm

  • Rated Rotated Speed 150 r/m

    Rated Wind Speed 8m/s

    Output Voltage 110V/220V/380V

    Start Up Wind Speed 1.5m/s

    Operating Wind Speed 1.5-25m/s

    Security Wind Speed 40m/s

    Output Controller System charger and inverter

    Suggest Battery 12V100AH 18pcs( or to what you require )

    Can Supply Power for Refrigerators, Washing machines, Water pumps, Cookers, Color television sets, Lighting, Electric fans, small AC ,Charge and so on



    Our design is C style with 5 blades, The blades of the VAWT were made by FRP by hands which is strong enough , higher quality and lighter weight . with Hot Air Path on the blades which can fully use of the wind the most , So the wind system can start at very low wind speed

    The efficiencies of our C shaped blades are 30% higher than other shaped blades .

    Our design use the permanent magnet generator and fine copper coil which can stand high temperature To guarantee the high efficiencies and long life time of the wind turbine .

    The controller is micro-computer control and The Inverter is Pure Sine Wave .
